BLOOD PRESSURE AND HEART RATE EFFECTS OF ANODAL TDCS ON LEFT TEMPORO-INSULAR CORTEX DURING CONSTANT AEROBIC EXERCISE IN HEART FAILURE PATIENTS
DOI: Pending DOI
Synopsis
Problem: Patients with HFrEF face significant hemodynamic risks during aerobic exercise, requiring strategies to ensure safe training.
Methods: In a double-blind, randomized, controlled trial, 22 HFrEF patients received active anodal tDCS over the left temporo-insular area (2 mA, 20 min) or sham stimulation during a single session of continuous aerobic exercise.
Results: Active tDCS significantly attenuated systolic blood pressure (SBP) at the end of exercise compared to sham (122±16 vs 140±19 mmHg, p=0.04). No significant differences were observed in diastolic blood pressure or heart rate between groups.
Conclusion: Acute left temporo-insular tDCS prevents excessive SBP elevation during exercise in HFrEF patients, potentially reducing cardiac afterload during physical exertion.
Background
Heart failure with reduced ejection fraction (HFrEF) is characterized by limited functional capacity due to impaired cardiac function, autonomic dysfunction, and inflammatory alterations1. Exercise-based rehabilitation is a cornerstone of HFrEF treatment, with strong evidence for functional improvement and reduced readmission2. However, barriers such as low adherence and resistance to improvement remain significant3. Studies in healthy volunteers have explored transcranial direct current stimulation (tDCS) effects on performance and hemodynamics4-6. Okano et al.4 found that anodal temporo-insular tDCS in amateur cyclists reduced perceived exertion and delayed cardiac vagal withdrawal during incremental exercise. Farinatti et al.6 reported increased post-exercise hypotension after tDCS over the perceptual area in healthy subjects. Given the hemodynamic risks of aerobic exercise in HFrEF patients, monitoring is essential for safe training. Therefore, this study aimed to evaluate the acute hemodynamic response to anodal temporo-insular tDCS during a single session of continuous aerobic exercise in patients with HFrEF. We hypothesized that stimulation attenuates blood pressure and heart rate responses to physical exertion in this population.
Methods
This is a double-blind, randomized, controlled study and part of the ELETRIC trial⁷. It was conducted at the cardiopulmonary physiology laboratory of Hospital Universitário Getúlio Vargas (UFAM, Manaus, Brazil), approved by the ethics committee (IRB#64652122.0.0000.5020) and registered in the Brazilian Clinical Trials Registry (#RBR-10w787j6). Volunteers were evaluated by a cardiologist and underwent a symptom-limited cardiopulmonary exercise test using a HandyMet metabolic cart (MDI, Brazil) and a CG 4 electromagnetic cycle ergometer (Inbramed, Brazil) following guidelines⁸. The workload at the anaerobic threshold was selected for exercise. After 2 adaptation sessions, outcomes were assessed in the third session. The exercise protocol consisted of 5min rest, 5min warm-up, 15min exercise at the anaerobic threshold and/or Borg 3 (moderate intensity), and 5min active cool-down on the cycle ergometer (Inbramed, Brazil). Anodal tDCS using a Focus Research device (NKL, Brazil) was applied over the left temporo-insular area with the cathodic electrode on the right supraorbital area (Figure 1) at 2mA for 20min, with a 30s ramp-up and ramp-down (during warm-up and exercise). Sham used a 30s ramp-up, 1 min of stimulation, then ramp-down. Systolic and diastolic blood pressure by aneroid sphygmomanometer and heart rate by finger pulse oximeter (Nonin, USA) were assessed. Statistical analysis: independent t-test, chi-square, ANOVA two-way mixed with Tukey's post hoc test (Jamovi and GraphPad Prism 9.0 were used), and p < 0.05 was accepted as statical significant.
Results
A total of 146 volunteers were contacted, of whom 27 were selected. Ultimately, 22 volunteers participated in the study and were divided into Sham (n=10) and tDCS (n=12) groups. Both the volunteer and the therapist were blinded. Volunteers had the following characteristics: age (Sham: 54±13 years; tDCS: 55±8 years, p=0.870), women (Sham: 30%; tDCS: 42%, p=0.571), BMI (Sham: 30.4±2.9 kg/m²; tDCS: 27.9±3.9 kg/m², p=0.107), LVEF (Sham: 34±6%; tDCS: 30±9%, p=0.107), VO2peak (Sham: 22.3±8.5 ml·kg⁻¹·min⁻¹; tDCS: 27±6.8 ml·kg⁻¹·min⁻¹, p=0.151), peak workload (Sham: 90.8±26.6 W; tDCS: 95.2±29.5 W, p=0.722), 6MWT (Sham: 494±64 m; tDCS: 461±99 m, p=0.368), NYHA III (Sham: 80%; tDCS: 59%, p=0.277). Patients showed no differences in comorbidities. There were also no differences in medication use. All patients were using beta-blockers, and sacubitril-valsartan was very common (Sham: 70%; tDCS: 75%, p=0.793). During training, a lower systolic blood pressure (SBP) was observed at the end of exercise, with a significant interaction (p=0.04, η²p=0.12; moderate to large effect size). The Sham group reached 140±19 mmHg of SBP, while the tDCS group reached 122±16 mmHg of SBP. Interestingly, resting SBP values were 110±11 mmHg in the Sham group and 109±15 mmHg in the tDCS group. Regarding diastolic blood pressure, there was no change at the end of exercise between groups. For heart rate, a similar increase was observed between groups, with no detectable impact of tDCS. Exercise workload was similar between groups, with a mean of 40±16 W in the Sham group and 42±16 W in the tDCS group (p=0.789).
Discussion
This is the first study to evaluate BP and HR behavior during physical exercise in patients with HFrEF during tDCS stimulation. The study demonstrated that left temporo-insular anode stimulation can prevent a large increase in SBP during continuous aerobic exercise. Integrative physiology studies have shown that there is an interaction of peripheral type III/IV receptors in the pressor response during physical exercise and central mediation of various areas of the central nervous system, mainly the left insula9,10. Evidence shows that the peripheral system is important in pressor hyperactivity during exercise in patients with HF11. The current study likely can regulate peripheral activation, even with patients using drugs that control BP behavior. Even though there was no negative behavior with the use of tDCS during exercise, it is still not known whether the pressor response effect is positive in this type of patient. We know that lower BP may be due to decreased cardiac output or vascular resistance, and to evaluate this question, further studies will be necessary8. However, due to the lack of symptomatology or BP increase followed by a pressure drop (common in output alterations), this was not observed in the study. Finally, one hypothesis that can be postulated is that the lack of BP increase during submaximal exercise may be a strategy to reduce the impact of afterload and decrease cardiac O₂ consumption in patients with coronary artery disease, favoring higher training loads in this population.
Disclosures
The authors declare no financial disclosures
References
1. Heidenreich PA, Bozkurt B, Aguilar D, Allen LA, Byun JJ, Colvin MM, Deswal A, Drazner MH, Dunlay SM, Evers LR, Fang JC, Fedson SE, Fonarow GC, Hayek SS, Hernandez AF, Khazanie P, Kittleson MM, Lee CS, Link MS, Milano CA, Nnacheta LC, Sandhu AT, Stevenson LW, Vardeny O, Vest AR, Yancy CW., ACC/AHA Joint Committee Members. 2022 AHA/ACC/HFSA Guideline for the Management of Heart Failure: A Report of the American College of Cardiology/American Heart Association Joint Committee on Clinical Practice Guidelines. Circulation. 2022 May 03;145(18):e895-e1032
2. O'Connor CM, Whellan DJ, Lee KL, Keteyian SJ, Cooper LS, Ellis SJ, Leifer ES, Kraus WE, Kitzman DW, Blumenthal JA, Rendall DS, Miller NH, Fleg JL, Schulman KA, McKelvie RS, Zannad F, Piña IL; HF-ACTION Investigators. Efficacy and safety of exercise training in patients with chronic heart failure: HF-ACTION randomized controlled trial. JAMA. 2009 Apr 8;301(14):1439-50.
3. Nelson RK, Solomon R, Hosmer E, Zuhl M. Cardiac rehabilitation utilization, barriers, and outcomes among patients with heart failure. Heart Fail Rev. 2023 Nov;28(6):1239-1249.
4. Okano AH, Fontes EB, Montenegro RA, Farinatti Pde T, Cyrino ES, Li LM, Bikson M, Noakes TD. Brain stimulation modulates the autonomic nervous system, rating of perceived exertion and performance during maximal exercise. Br J Sports Med. 2015 Sep;49(18):1213-8.
5. Silva-Filho E, Albuquerque J, Bikson M, Pegado R, da Cruz Santos A, do Socorro Brasileiro-Santos M. Effects of transcranial direct current stimulation associated with an aerobic exercise bout on blood pressure and autonomic modulation of hypertensive patients: A pilot randomized clinical trial. uton Neurosci. 2021 Nov: 235:102866.
6. Farinatti P. Cordeiro R, Vogel M, Machado S, Monteiro W. Postexercise blood pressure and autonomic responses after aerobic exercise following anodal tDCS applied over the medial prefrontal cortex. Neurosci Lett. 2019 Oct 15:711:134444.
7. da Silva VCC, da Silva Arêas FZ, Lopes ALRB, de Almeida E Val FF, da Costa AG, Dos Santos JCC, Ferreira JMBB, Peixoto Tinoco Arêas G. Anodal transcranial direct current stimulation associated with aerobic exercise on the functional and physical capacity of patients with heart failure with reduced ejection fraction: ELETRIC study protocol. Trials. 2023 Nov 17;24(1):738.
8. Guazzi M, Arena R, Halle M, Piepoli MF, Myers J, Lavie CJ. 2016 Focused Update: Clinical Recommendations for Cardiopulmonary Exercise Testing Data Assessment in Specific Patient Populations. Circulation. 2016 Jun 14;133(24):e694-711.
9. Williamson JW, Nobrega AC, McColl R, Mathews D, Winchester P, Friberg L Mitchell JH. Activation of the insular cortex during dynamic exercise in humans. J Physiol. 1997 Sep 1;503 ( Pt 2)(Pt 2):277-83.
10. Teixeira AL and Vianna L. The exercise pressor reflex: An update. Clin Auton Res. 2022 Aug;32(4):271-290.
11. Hoch JW, Domeier C, Silvestri P, Watso JC. Prognostic value of exercise blood pressure: role of fitness and exercise training. Am J Physiol Heart Circ Physiol. 2026 Apr 1;330(4):H1025-H1047.
